MAX30102 心率血氧感測器(適用樹莓派、Arduino)

MAX30102 心率血氧感測器(適用樹莓派、Arduino)

貨號:CSH0020


NT$800
{{shoplineProductReview.avg_score}} {{'product.product_review.stars' | translate}} | {{shoplineProductReview.total}} {{'product.product_review.reviews' | translate}}
{{amazonProductReview.avg_rating}} {{'product.product_review.stars' | translate}} | {{amazonProductReview.total_comment_count}} {{'product.product_review.reviews' | translate}}
數量 組合數量
加入追蹤清單
一次最大商品購買數量限制為 99999
該數量不適用,請填入有效的數量。
售完

商品存貨不足,未能加入購物車

您所填寫的商品數量超過庫存

{{'products.quick_cart.out_of_number_hint'| translate}}

{{'product.preorder_limit.hint'| translate}}

每筆訂單限購 {{ product.max_order_quantity }} 件

現庫存只剩下 {{ quantityOfStock }} 件

若想購買,請聯絡我們。
加入追蹤清單
商品描述
了解更多
送貨及付款方式
顧客評價
【產品簡介】

DFRobot Gravity: MAX30102 heart rate and blood oxygen sensor module integrates the Maxim MAX30102 chip and an MCU with heart rate and blood oxygen algorithm.
The MAX30102 uses PPG(PhotoPlethysmoGraphy) to measure data, which will be converted into heart rate and oximetry values when processed by the MCU, then output through I2C or UART, making the sensor easy to use and greatly reducing resource occupation of the main controller. Meanwhile, the corresponding upper computer is provided to allow you to conveniently read data by a PC.

  • The pressure may change when the finger is directly pressed down the sensor, which will affect the data output. So please try to fix the sensor on your finger.
  • Wear the sensor on your finger and there is no difference in the direction of wearing.
  • This product is not a professional medical instrument and should not be used as an auxiliary accessory in diagnosis and treatment



【產品規格】

  • Power Supply Voltage: 3.3V/5V
  • Working Current: <15mA
  • Communication Method: I2C/UART
  • I2C Address: 0x57
  • Serial Port Baud Rate: 9600
  • Operating Temperature Range: -40℃~85℃
  • Product Size: 25.5×32mm/0.98×1.26inch


【產品特色】

  • Microcontroller with algorithm integrated
  • Data can be read directly through the host computer

【產品應用】

  • Heart rate blood oxygen project
  • Home heart rate oximeter
  • Long-term heart rate and blood oxygen monitoring project

【出貨清單】

  • Gravity: MAX30102 Heart Rate and Oximeter Sensor x1
  • Gravity-4P I2C/UART Sensor Connector x1
  • Strap x1

【文件下載】









這個商品沒有更多資訊。

送貨方式

  • 郵寄掛號 (未滿一千元須加運費60元;會員滿千免運)
  • 順豐速運 (運費100元)
  • 7-11 取貨付款 (運費60元)
  • 7-11 純取貨 (運費60元)
  • 全家 取貨付款 (運費60元)
  • 全家 純取貨 (運費60元)
  • 面交自取

付款方式

  • 銀行轉帳 (請於3日內匯款完成)
  • 信用卡 (金額需要滿三千元才能使用)
  • 全家 取貨付款
  • 7-11 取貨付款
  • 面交付款
